Humbucker Electric Guitar Pickguard Pickup with Singlecut Wiring Loaded Prewired Pickguard SSH Guitar Pickguard Swith Control Scratchplate Assembly for Fender Strat Guitar (Black)
4.5 (117 items)
Limited Time SaleUS$28.47 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 215949164 | Release Date | 2026/04/19 | List Price | US$18.98 | Model Number | 215949164 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The DIAO79NI Small Dual Rail with Coil-Split Pickguard Combo features a precisely crafted PVC pickguard (281mm/11.06"L x 222mm/8.74"W) housing two mini humbuckers and one full-size dual-coil pickup with copper wiring. The 5-way selector switch works with three ON/ON mini switches for coil splitting, complemented by a dedicated mute switch and ceramic magnets for enhanced articulation. Control includes 1 master volume and 2 tone knobs.Technical Specifications:DC Resistance: Neck/Middle: 7kΩ (3.5kΩ split) Bridge: 12kΩ (6kΩ split)4-conductor wiring: Black (hot), Green (ground), Red/White (coil split)11 pre-drilled screw holes (minor adjustments may be required for perfect alignment)13 color options availableNote: While compatible with most ST-style guitars, slight modifications might be necessary to match specific screw hole patterns. Includes all required hardware for installation.
- 【Professional Sound Configuration】Two mini humbuckers paired with a full-size dual-coil pickup deliver powerful output (7kΩ-12kΩ) with coil-split versatility for both thick distortion and single-coil clarity.
- 【Advanced Switching System】5-way selector + three 2-way ON/ON switches enable 8 tonal variations, plus dedicated mute switch for instant silent tuning.
- 【Universal Fit】Precision-cut PVC pickguard (11.06"x8.74") fits most ST-style guitars - 13 color options match any aesthetic.
- 【Studio-Grade Wiring】4-conductor shielded cables with color-coded connections (black=hot, green=ground) ensure noise-free performance and easy installation.
- 【Installation Ready】Includes 11-hole mounting system with ceramic magnet pickups - minor adjustments may be needed for perfect alignment.
| Color Name | Black |
|---|---|
| Item Weight | 0.508 ounces |
| Item model number | AMZ-GT-500 |
| Package Dimensions | 0.78 x 0.78 x 0.31 inches |
